WebBright™ Lightbox 80mm

Moss Radiance is a comprehensive line of spectacularly brilliant indoor fabric light boxes for trade shows, events & retail stores. These sleek, bright LED lightboxes are economical to operate, boldly display backlit graphics and are ETL Listed to meet UL safety standards. Moss’ proprietary LED WebBright™ lattice was developed exclusively for excellent light uniformity and energy efficiency. The WebBright 80mm Lightbox is ADA compliant regarding projection from walls.

Features & Benefits

The Moss Radiance WebBright™ 80mm Lightbox is a beautiful Lightbox perfect for a big, bold statement. WebBright™ Lightbox uses our patented Tension Lock™ corners for fast, strong frame assembly. No loose parts and tiny screws to lose. The LED lattice ships flat for compact shipping and easy assembly.

Fabric & Graphics

Super vivid, glare-free, and extra sharp Photo Fabric® graphics result in dramatic visual impact. Colors pop to life with Radiance rear illumination. Moss® offers 10ft seamless graphics for extra large light box solutions. Installation and graphic replacement is easy, minimizing installation costs. A clean, tensioned fit is ensured with our unique tension strip. The durable fabric is machine washable for easy cleaning. Compact and lightweight fabric graphics reduce shipping costs.


The Moss WebBright Lightbox comes with LED flat for compact shipping – simply snap the lattice to the frame. The LED modules are an energy efficient lighting solution, only using 5 watts per square foot with a LED life expectancy of 50,000+ hours. Field maintenance is easy with replacement lattice strips. All lighting components are UL approved high voltage components. All Moss Radiance Lightboxes are ETL Listed for the U.S. and Canada and meet UL standards for safety.

Display Options

Use the WebBright LED Lightbox free standing, hanging or wall mounted. Add base plates for free standing light boxes. Base Plates are available in multiple sizes and configurations to stabilize & support any light box. Add Z-shaped cleats attached to the wall and hang the Moss Radiance light box on the cleats for an easy and quick installation. To hang simply suspended from the ceiling or other structural supports by attaching eye bolts to the framing.

This product is covered by one more of the following U.S. Patent Number(s): 8,956,071 as well as additional pending U.S. Patent(s) owned by Moss Holding Company.

Product Details:

At 80mm in thickness, WebBright 80mm is ADA compliant under guidelines for wall projection/wall-mount installation.

Maximum seamless graphic size:
15ft. x 50ft. for UV print
10 ft. x 50ft. for dye sub print

Clean, bright white lighting at 6,000 degrees Kelvin

Energy-efficient 75W power supply using as little as 5.28 W/sq. ft.

For optional self-standing applications, available thru-bolt baseplates recommended for lightboxes up to 6 ft. tall, and custom bookend baseplates recommended for lightboxes taller than 6 ft.

Maximum 8 ft. long x 2 ft. wide lattice

LED life expectancy of 50,000+ hours

2-year warranty on lattice
